AFFORDABLE COST.
SMALL SIZE.
EXTENSIBILITY.
MODULAR ACTUATOR
OPEN SOURCE SOFTWARE.
OPEN SOURCE HARDWARE.
STRONG SENSOR LINEUPS.
for Full Scale Robots
Full Modular Solution.
Sophisticated Control Algorithms
Noval Gear Reducation System.
New products
View more productstemi
A premium designed, video-oriented, autonomous personal AI assistant robot. temi can recognise and follow when requested, save preset locations, and navigate flawlessly around your home and office while connecting you to your friends, family and favorite web services.
Promobot V.4
What is Promobot? Promobot is an autonomous robot designed for business purposes. It is able to communicate with people on any topic, recognize faces, answer questions, move around avoiding obstacles, move its arms and head, show various materials on its display and integrate with third-party devices and systems. To date,...
ROBOTIS ENGINEER KIT 2
Robotis Engineer Kit2 require components form the Robotis Engineer Kit1 in order to assemble the example robots.
All products
View more productsXH430-V210-R
[902-0130-000] XH430-V210-R ■ Basic Features The DYNAMIXEL X-Series is a new line-up of high performance networked actuators. For more detailed information, please visit the DYNAMIXEL X-Series Product Information page. • Improved Torque, Compact Design • Enhanced Durability and Expandability • Hollow Back Case Minimizes Cable Stress (3-Way Wiring) • Frames Directly Screwed onto the Case (No Nuts...
L54-50-S290-R
Requires 4 weeks of lead time upon order.
[902-0080-000] L54-50-S290-R
Characteristics
- DYNAMIXEL Pro is an integrated actuator composedof a gear reduction system, controller,
driver, and network for constructing modular robots.
- A detachable cycloidal gear reduction box.
- Position, speed, and current control using an algorithm.
- Torque control using current sensor.
- PID control is used to sense position.
- Resolution: Max 207,720 (steps/1 full rotation)
Components
Components | Quantity | |
DYNAMIXEL Pro | L54-50-S290-R | 1 |
Cable | 4P Cable 600MM | 2 |
2P External Power Connector 600MM | 1 | |
Bolt | Wrench Bolt (WB M3*8) | 20 |
Specifications
Model Number | L54-50-S290-R | |
Weight | 0.662kg (23.1oz) | |
Size | 54x54x108(mm)
2.13x.2.13x4.25(in) |
|
Rated voltage | 24 V | |
No load speed | 26 RPM | |
No load current | 1.05 A | |
Continuous operation | Speed | 22.1 RPM |
Torque | 4.8 Nm (680 ozf.in) | |
Current | 1.9 A | |
Resolution | 207,720 Steps/turn | |
Gear ratio | 289:1 | |
Backlash | 4.6 arcmin | |
Interface | RS-485 | |
Operating temperature | 5~55℃ |
Default Settings
- ID: 1
- Baud Rate: 1 (57600bps)
(Please make necessary modifications, suchas the ID, baud rate, etc…, after the purchase.)
Caution
- L54-50-S290-R supports RS-485 communication.
- L54-50-S290-R has a Straight type reduction gear system.
- Caution: The operational voltage is different from other DYNAMIXEL series.
(Operational voltage: 24V)
■ Hyperlinks
Frame, Idler Compatible Chart : Click Here
Download Drawing : Click Here
DXL SDK 3.0 for Windows/Linux (Github): Click Here
OpenCM IDE : Click Here
Link to e-Manual : Click Here
Mi Rabbit
Precision mechanical transmission structure, layers of progressive stitching fun Mi Rabbit building blocks of 978 pieces of high-precision molds injection molding. Gear set, chain, universal shaft, precision mechanical transmission structure can also ensure efficient action execution. All parts of the robot are made of non-polluting safety Made of material, can...
L54-30-S400-R
Requires 4 weeks of lead time upon order. [902-0090-000] L54-30-S400-R Characteristics – DYNAMIXEL Pro is an integrated actuator composedof a gear reduction system, controller, driver, and network for constructing modular robots. – A detachable cycloidal gear reduction box. – Position, speed, and current control using an algorithm. – Torque...
ROBOTIS Mini
– ROBOTIS MINI now support iOS! – iOS users can now use the ROBOTIS MINI using BT-410 (sold separately) – If you are an iOS user, please make sure to purchase BT-410 together. * Voice Recognition mode is NOT available for the iOS ROBOTIS MINI App. Please download the relevant...
L42-10-S300-R
Requires 4 weeks of lead time upon order. [902-0092-000] L42-10-S300-R Characteristics – DYNAMIXEL Pro is an integrated actuator composedof a gear reduction system, controller, driver, and network for constructingmodular robots. – A detachable cycloidal gear reduction box. – Position, speed, and current control using an algorithm. – Torque control...
OpenCR1.0
[903-0257-000] OpenCR1.0 ■ Basic Features OpenCR1.0 (Open-source Control module for ROS) is an open source robot controller embedded with a powerful MCU from the ARM Cortex-M7 line-up. The hardware, software, schematics, PCB Gerber, BOM, and firmware source codes of the OpenCR1.0, the main controller used in the official ROS education platform...
XH430-W350-R
[902-0120-000] XH430-W350-R ■ Basic Features The DYNAMIXEL X-Series is a new line-up of high performance networked actuators. For more detailed information, please visit the DYNAMIXEL X-Series Product Information page. Improved Torque, Compact Design Enhanced Durability and Expandability Hollow Back Case Minimizes Cable Stress (3-Way Wiring) Frames Directly Screwed onto the Case...
XL430-W250-T
XL430-W250-T ■ Basic Features The DYNAMIXEL X-Series is a new line-up of high performance networked actuators. The Dynamixel XL series adopts new features that allow 360 degrees control mode with its contactless magnetic encoder and hollow back case assembly structure. The XL series has the same mechanical structure as the XM430...
Jaguar V4
Jaguar V4 Mobile Robotic Platform is designed for indoor and outdoor applications requiring robust maneuverability and terrain maneuverability. It comes with four articulated arms and is fully wirelessly 802.11N connected. It integrates outdoor GPS and 9 DOF IMU (Gyro/Accelerometer/ Compass) for autonomous navigation. Jaguar V4 platform is rugged, light weight...
Promobot V.4
What is Promobot? Promobot is an autonomous robot designed for business purposes. It is able to communicate with people on any topic, recognize faces, answer questions, move around avoiding obstacles, move its arms and head, show various materials on its display and integrate with third-party devices and systems. To date,...
temi
A premium designed, video-oriented, autonomous personal AI assistant robot. temi can recognise and follow when requested, save preset locations, and navigate flawlessly around your home and office while connecting you to your friends, family and favorite web services.
MX-64R
[902-0065-000] MX-64R **Caution – MX-64R supports RS-485 communication. – Recommended voltage of MX-64 is different with that of former RX-64. – Operating Voltage : 10~14.8V (Recommended Voltage: 12V) DESCRIPTION: DYNAMIXEL is a robot exclusive smart actuator with fully integrated DC Motor + Reduction Gearhead + Controller + Driver +...
XH430-W350-T
[902-0126-000] XH430-W350-T ■ Basic Features The DYNAMIXEL X-Series is a new line-up of high performance networked actuators. For more detailed information, please visit the DYNAMIXEL X-Series Product Information page. • Improved Torque, Compact Design • Enhanced Durability and Expandability • Hollow Back Case Minimizes Cable Stress (3-Way Wiring) • Frames Directly Screwed onto the Case (No...
MX-106 Gear/Bearing Set
MX-106 Gear/Bearing Set DESCRIPTION – This gear set is for the Dynamixel MX-106. – Made with metal and specially coated to strengthen endurance and durability of abrasion. – A MX-106 exclusive magnet is attached to the wheel gear. – There are 2 wheel bearings included. – NOT compatible with the EX-106+. ...
X-80
X80 is now available in four colors: Orange, Green, Blue and Red. This ready to use mobile robot platform is designed for researchers developing advanced robot applications such as remote monitoring, telepresence and autonomous navigation/patrol. Mechanics The X80 is the result of extensive efforts to develop a robot that would...
LIPO Battery Charger LBC-010
Features – This charger is intended for the Li-Po battery. – Uses the SMPS for power when charging, thus it must be accompanied with the SMPS 12V 5A. – Support 2S and 3S Cell charge. (Exception, does not charge simultaneously) Package Components LIPO Battery Charger LBC-010 1 * Battery and...
XM430-W350-R
[902-0118-000] DYNAMIXEL XM430-W350-R The DYNAMIXEL X-Series is a new line-up of high performance networked actuators. For more detailed information, please visit the DYNAMIXEL X-Series Product Information page. ■ Basic Features • Improved Torque, Compact Design • Enhanced Durability and Expandability • Hollow Back Case Minimizes Cable Stress (3-Way Wiring)...
